| 10/100 Port | Yok |
| Combo Özelliği | Var |
| Gigabit RJ45 Port | 24 |
| Kasa Tipi | Rackmount |
| Poe Özelliği | Yok |
| RJ45 Uplink | 4X Gigabit RJ45 |
| SFP Girişi & SFP Uplink | 4X Gigabit SFP UPLINK |
| Toplam Port Sayısı | 24 |
| Yönetilebilirlik | Var |
| Açıklama | Genel Özellikler Interfaces Ports : 20 x 10/100/1000Base-T , 4 x Combo 10/100/1000Base-T/SFP Ports (Auto MDI/MDIX)/SFP Ports (IEEE 802.3u, 802.3z, 802.3ab, 802.3az compliant) Optional Redundant Power Supply : DPS-200 Console Port : 1 x RJ-45 Stacking Ports : 2 SD Card Slots : 1 Performance Switching Capacity : 88 Gbps 64-Byte Packet Forwarding Rate : 65.48 Mbps Status/duplex/speed information LED Optional Management Software DV-600S D-View 6.0 Network Management System (Standard Edition) DV-600P D-View 6.0 Network Management System (Professional Edition) Optional Accessory DEM-CB50 50 cm Stacking Cable DEM-CB100 100 cm Stacking Cable DEM-CB300 300 cm Stacking Cable DEM-CB50ICX 50 cm Cable for connecting with CX4 devices Optional Redundant Power Supply DPS-200 60 watt Redundant Power Supply Optional SFP Transceivers DEM-712 1000BASE-T Copper SFP Transceiver DEM-310GT 1000BASE-LX, Single-mode, 10 km DEM-311GT 1000BASE-SX, Multi-mode, 500 m DEM-312GT2 1000BASE-SX, Multi-mode, 2 km DEM-314GT 1000BASE-LHX, Single-mode, 50 km DEM-315GT 1000BASE-ZX, Single-mode, 80 km DEM-210 100BASE-FX, Single-mode, 15 km DEM-211 100BASE-FX, Multi-mode, 2 km Optional WDM SFP Transceivers DEM-330T 1000BASE-LX, Wavelength Tx:1550 nm Rx:1310 nm, Single-mode, 10 km DEM-330R 1000BASE-LX, Wavelength Tx:1310 nm Rx:1550 nm, Single-mode, 10 km DEM-331T 1000BASE-LX, Wavelength Tx:1550 nm Rx:1310 nm, Single-mode, 40 km DEM-331R 1000BASE-LX, Wavelength Tx:1310nm Rx:1550 nm, Single-mode, 40 km DEM-220T 100BASE-BX, Wavelength Tx:1550nm Rx:1310 nm, Single-mode, 20 km DEM-220R 100BASE-BX, Wavelength Tx:1310nm Rx:1550 nm, Single-mode, 20 km Operating Temperature : 0 to 50 °C Storage Temperature : -40 to 70 °C Operating Humidity : 10% to 90% RH Storage Humidity : 5% to 90% RH Emission (EMI) : FCC Class A, CE Class A, VCCI Class A, IC, C-Tick, BSMI FCC Class A, CE Class A, VCCI Class A, IC, C-Tick Safety : CB, cUL, LVD, BSMI CB, cUL, LVD Certification : IPv6 Ready Logo Phase 2 Fiziksel Özellikler Software Features - Standard Image (SI) Features Stackability • Physical Stacking • Up to 40G Stacking Bandwidth • Up to 6 units per Stack • Virtual Stacking • D-Link Single IP Management (SIM) • Up to 32 units per Virtual Stack L2 Features • MAC Address Table: 16K entries • Flow Control • 802.3x Flow Control • HOL Blocking Prevention • Jumbo Frames up to 13 Kbytes • 802.3ad Link Aggregation • Max. 32 groups per device, 8 Gigabit ports per group • Spanning Tree Protocols • 802.1D STP • 802.1w RSTP • 802.1s MSTP • BPDU Filtering • Root Restriction • Loopback Detection • Port Mirroring • One-to-One • Many-to-One • Flow-based • RSPAN Mirroring L2 Multicasting • IGMP Snooping • IGMP v1/v2/v3 Snooping • Supports 1024 IGMP groups • Port/Host-based IGMP Snooping Fast Leave • Limited IP Multicast • Up to 24 IGMP filtering profiles,32 ranges per profile • MLD Snooping • MLD v1/v2 Snooping • Support 1024 MLD Groups • Host-based MLD Snooping Fast Leave VLAN • VLAN Group • Max. 4K Active VLAN Groups • GVRP • Max. 4K Dynamic VLAN Groups • 802.1Q Tagged VLAN • Port-based VLAN • 802.1v Protocol VLAN • Voice VLAN • MAC-based VLAN • ISM VLAN • Asymmetric VLAN • Private VLAN • VLAN Trunking QoS (Quality of Service) • 802.1p • 8 queues per port • Queue Handling • Strict Priority • Weighted Round Robin (WRR) • Strict + WRR • Supports following actions for flows • Remark 802.1p Priority Tag • Remark TOS/DSCP Tag • Bandwidth Control • CoS based on • Switch Port • VLAN ID • 802.1p Priority Queues • MAC Address • IPv4 Address • DSCP • Protocol Type • TCP/UDP Port • User-Defined Packet Content • IPv6 Address • IPv6 Traffic Class • IPv6 Flow Label • Bandwidth Control • Port-based (Ingress/Egress, Min.Granularity 8 Kbps) • Flow-based (Ingress/Egress, Min.Granularity 8 Kbps) • Three Color Marker • CIR/PIR minimum granularity: 8kbps • Two Rate Three Color Marker (trTCM), CBS/PBS • Single Rate Three Color Marker (srTCM), CBS/EBS Access Control List (ACL) • ACL based on • 802.1p Priority • VLAN ID • MAC Address • Ether Type • IPv4 Address • DSCP • Protocol Type • TCP/UDP Port Number • User-Defined Packet Content • IPv6 Address • IPv6 Flow Label • IPv6 Traffic Class • Supports up to 1.5K Ingress access rules • Time-based ACL • CPU Interface Filtering Security • SSH v2 • SSL v1/v2/v3 • Port Security • Up to 64 MAC addresses per port/ VLAN • Broadcast/Multicast/Unicast Storm Control • Traffic Segmentation • D-Link Safeguard Engine • NetBIOS/NetBEUI Filtering • DHCP Server Screening • DHCP protection • DoS Attack Prevention • BPDU Attack Protection • Dynamic ARP protection • IP source guard • Root protection • Loop protection AAA • 802.1X: • Port-based Access Control • Host-based Access Control • Identity-driven Policy (VLAN, ACL or QoS) Assignment • Authentication Database Failover • Web-based Access Control (WAC): • Port-based Access Control • Host-based Access Control • Identity-driven Policy (VLAN, ACL or QoS) Assignment • Authentication Database Failover • MAC-based Access Control (MAC): • Port-based Access Control • Host-based Access Control • Identity-driven Policy (VLAN, ACL or QoS) Assignment • Authentication Database Failover • Japan Web-based Access Control (Host-based JWAC) • Guest VLAN • Microsoft® NAP • Support 802.1X NAP • Support DHCP NAP • RADIUS Accounting • TACACS+ Accounting • RADIUS and TACACS authentication for switch access • Four levels of User Account control Green Features • Compliant with RoHS • Diagnostic LEDs Power,Link, Status • Power Saving by Cable Length, Link Status • Time-based PoE • IEEE 802.3az Energy Efficient Ethernet (EEE) Operation, Administration & Management (OAM) • Cable Diagnostics Management • Web-based GUI • Command Line Interface (CLI) • Telnet Server • Telnet Client • TFTP Client • DNS Client • Secure FTP Server • ZModem • SNMP v1/v2c/v3 • SNMP Traps • System Log • RMON v1: • Supports 1,2,3,9 groups • RMON v2: • Supports ProbeConfig group • LLDP, LLDP-MED • BootP/DHCP Client • DHCP Auto-Configuration • DHCP Relay • DHCP Client Option 12 • DHCP Relay Option 18, 37, 82 • Flash File System • Multiple Images • Multiple Configurations • CPU Monitoring • Debug Command • SNTP • Password Recovery • Password Encryption • Trusted Host • Microsoft® NLB (Network Load Balancing) Support • ICMPv6 MIB • RFC 1213 MIB II • RFC 4188 Bridge MIB • RFC 1157, 2571-2576 SNMP MIB • RFC 1907 SNMPv2 MIB • RFC 1757, 2819 RMON MIB • RFC 2021 RMONv2 MIB • RFC 1398, 1643, 1650, 2358, 2665 Ether-like MIB • RFC 2674 802.1p MIB • RFC 2233, 2863 IF MIB • RFC 2618 RADIUS Authentication Client MIB • RFC 2620 RADIUS Accounting • Client MIB • RFC 2925 PING & TRACEROUTE MIB • RFC 2674, 4363 802.1p MIB • RFC 1065, 1066, 1155, 1156, 2578 MIB Structure • RFC 1215 MIB Traps Convention • RFC 1212 Concise MIB Definitions • RFC 1215 MIB Traps Convention • RFC 1157, 2571-2576 SNMP MIB • RFC 4022 MIB for TCP • RFC 4113 MIB for UDP • RFC 4293 IPv6 SNMP Mgmt Interface MIB • RFC 2737 Entity MIB (version 2)RFC Standard Compliance • RFC 768 UDP • RFC 791 IP • RFC 792, 2463, 4443 ICMP • RFC 793 TCP • RFC 826 ARP • RFC 3513, 4291, IPv6 Addressing Architecture • RFC 2893, 4213 IPv4/IPv6 dual stack function • RFC 2463, 4443 ICMPv6 • RFC 2462, 4862 IPv6 Stateless Address Auto Configuration • RFC 2464 IPv6 Ethernet and definition • RFC 1981 Path MTU Discovery for IPv6 • RFC 2460 IPv6 • RFC 2461, 4861 Neighbor Discovery for IPv6 • RFC 783 TFTP • RFC 2068 HTTP • RFC 1492 TACACS • RFC 2866 RADIUS Accounting • RFC 2474, 3260 DiffServ • RFC 1321, 2284, 2865, 3580, 3748 Extensible • Authentication Protocol (EAP) • RFC 2571, 2572, 2573, 2574, SNMP • IPv6 Ready Logo Phase 2 • RFC 854 Telnet • RFC 951, 1542 BootP Software Features - Enhanced Image (EI) Features L2 Features • Ethernet Ring Protection Switching (ERPS) VLAN • Double VLAN (Q-in-Q) • Port-based Q-in-Q L3 Features • Max. 16 IP Interfaces • ARP Proxy • IPv6 Neighbour Discovery (ND) L3 Routing • Static Route • 512 static routing entries for IPv4/IPv6 Access Control List (ACL) • Supports up to 512 egress access rules Security • IP-MAC-Port Binding • Dynamic ARP protection • IP Packet Inspection • DHCP Snooping • DHCP Protection • Support up to 510 Address Binding Entries per Device • IP Source guard • IPv6 ND Snooping • BPDU Guard • Root Protection • Loop Protection AAA • Compound Authentication Operation, Administration & Management (OAM) • 802.3ah Ethernet Link OAM • 802.3ah D-Link Extension: D-link Unidirectional Link Detection (DULD) • 802.1ag Connectivity Fault Management (CFM) • ITU-T Y.1731 Management • sFlow • PPPoE Circuit-ID Tag Insertion Software Features - Routed Image (RI) Features L3 features • VRRP • IPv6 Tunneling L3 Routing • RIPv1/ v2 • OSPF • IP Directed Broadcast L3 Multicasting • IGMPv1/v2/v3 • MLD • IGMP/MLD Proxy • Multicast Duplication • PIM DM • PIM SM • PIM SSM • PIM Spare-Dense Mode • DVMRPv3 |
